Laminating in Biscuits Making Process

Laminating is the biscuit or cooking making process by which a layered structure is built up through the rolling of the dough, folding it, then turning it through 90 degrees at least once before the final cutting thickness is gauged.

During this stage of biscuit and cookie production, gluten is developed which gives the baked product a delicate flaky structure. Often, another material such as fats for biscuit will be introduced between the layers for purposes of encouraging further separation of these layers during the baking process.


Laminating process

Any developed hard dough can be laminated with benefit during the process of biscuit or cookie production. Lamination allows for the creation of clearer dough, as well as the introduction of fat and flour mixtures designed to keep the layers of dough separated during the baking process. Most important to the overall structure of the cookie or biscuit is the dough sheet/ stress relief that the laminator provides.

For puff biscuits and cookies, a lot of fat is introduced between the layers of dough, thereby producing a structure that is very flaky. This fat may be introduced into the dough in the form of knobs before sheeting takes place, or even as a continuous layer following the formation of a good dough sheet. Both cases require gauging and laminating for the subsequent build-up of the number of dough layers that may appear in the form of very thin flakes in the baked cookie or biscuit.

An important feature of the production of this dough is the plasticity of the fat or fat/ flour mixture that is utilized. It is important that the consistency of the dough and fat be very similar such that the fat does not break through the dough layer or on the other hand end up being squeezed out. The baker will need to ensure that the fat utilized does not end up with a large high melting point tail above body temperature. To achieve a dough that is sufficiently plastic and firm in consistency, you will need to arrange for the dough to be cold, typically not more than 18 degrees.

Types of Machines Used In the Process

Laminators use precision motor control for the accurate cutting, stacking, and delivery of laminated dough to the downstream forming and reduction equipment. Sheets of dough are moved to the discharge conveyor through the layering carriage, which then deposits the sheets by extending these to the far edge of the laminator take-away conveyor. While conveying, the carriage will retract ad thereby gently lay the sheets on top of the lamination stack which is moving.

As the lapper in the laminator builds up the dough layers, it is crucial to make adjustments to the speed such that the exact same number of laps is present all the time. It is important to avoid the occurrence of a variable thickness which can cause the feeding to the next gauge roll to be uneven, with irregular stresses being set up in the dough on gauging to a final thickness.

Vertical Laminator

Vertical Laminator

This laminator is typically comprised of a three roll sheeter incorporated with cutter scrap, 2-3 gauge rolls, dust spreader on part of the sheet, as well as a lapper with a capacity of building up approximately 10-12 layers. Such a laminator is advantageous in that it allows for the continuous smooth action of most of the parts.

Another advantage of vertical laminators is that they allow for the continuous spread of filling over the full width of the sheet. Vertical laminators are ideal for plants that wish to save floor space through the elimination of canvas webs between gauge rolls, thereby saving a lot of machinery. Different types of vertical laminators are available with designs that feature resting webs between the gauging stations.

Horizontal Laminator

Similar in performance to their vertical counterparts, horizontal laminators have units spread out horizontally before the lapper on which the sheeting, gauging and dust filling will take place. This may be supplied by a cut sheet lapper in which case the dough sheet is laid down only with the retraction of the lapper. In such a case, only the top of the dough sheet will appear on the laminated dough pile. The key advantage to this is that little or no stress will occur at the edges as no folding takes place. In addition, an in-line laminating arrangement may also be an option.

One advantage to this type of laminator is the fact that multiple lappers may be used where required, which allows for the introduction of a second turn to the dough. It is common to use 2 three roll sheeters in horizontal laminators, with more fatty fillings being added onto the lower dough sheet, between the two sheets. In this laminator, the width of the laminated dough pile may be controlled by paying attention to the laminating section. In addition, the number of formed layers may be altered through the adjustment of the relative speed of the conveyer that takes the laminated dough away. The faster the running of this conveyor, the fewer the number of layers that will result.

Horizonal Laminator

Potential problems and solutions

  • Bands of Stretched or Crushed Dough – Where the dough emerges in stretched or crushed bands from the next gauge roll, this may be a problem with lamination. In such an instance, you may open or close the space between each lap by simply altering the speed of the laminator.
  • Uneven Weights/ Lifts – Where the biscuit or cookie emerges with an uneven lift or weight that affects it's eating and coloration qualities, this may be a lamination problem. To fix this, ensure that the amount of filling introduced between laminations is uniform such that it doesn’t negatively impact the shape and quality control of the baked cookie or biscuit.
  • Ragged Flaky Structured Cookie or Biscuit – A cookie or biscuit that splits open along the lamination lines might be a result of too few laminations. On the other hand, too many laminations will cause excessive crushing and a product with poorly developed thickness. This can be countered by laminating a thinner dough sheet.
  • Poor Quality Edge-Lanes – If the biscuits or cookies emerge with poor quality edge lanes, carefully observe the gauging after the laminator. In the event that the width of the laminated dough is too great, crushing will have occurred at the edges. On the other hand, if the width of the laminated dough is too narrow, then you will be able to notice some pulling quite clearly. To correct this problem, simply adjust the length of the stroke of the laminator carriage.
